三溴化硼11

Boron11 Tribromide


产品介绍 Product introduction

        三溴化硼11（B11Br3）在常温常压下为具有刺鼻恶臭的无色发烟液体，能放出刺激性蒸气，遇水及受热分解放出有毒气体HBr。不溶于水，与乙醇、醚等的氧化物不生成附加化合物，但与胺类、磷烷类作用生成多种附加化合物。三溴化硼能与许多电子对给予体（如含磷、氮、砷、氧、硫和卤素等物质）反应生成酯位化合物。高纯三溴化硼11在半导体工业用作掺杂源。
Boron tribromide(BBr3) is a kind of colorless fuming liquid with pungent odor at normal temperature and pressure. BBr3 can release irritating steam, it releases toxic gas HBr when it is heated or exposed to water. BBr3 is insoluble in water, it does not form additional compound with oxides such as ethanol and ether, but it reacts with amines and phosphorane to form a variety of additional compounds. Boron tribromide can react with a lot of electron pair donor (such as phosphorus, nitrogen, arsenic, oxygen, sulfur and halogen) to form ester compounds. High pure boron11 tribromide is used as doping source in semiconductor industry.

产品指标 Quality specification

项目Items 单位Units 指标Indexs
三溴化硼11 Boron11 Tribromide≥ ω/% 99.9999 (6N) 99.99999 (7N)
铝Aluminum≤ ω/(μg/kg) 10 5
锑Antimony≤ ω/(μg/kg) 10 3
砷Arsenic≤ ω/(μg/kg) 4 1
钡Barium≤ ω/(μg/kg) 2 1
铋Bismuth≤ ω/(μg/kg) 2 1
镉Cadmium≤ ω/(μg/kg) 2 1
钙Calcium≤ ω/(μg/kg) 10 5
铬Chromium≤ ω/(μg/kg) 2 1
钴Cobalt≤ ω/(μg/kg) 2 1
铜Cuprum≤ ω/(μg/kg) 5 2
镓Gallium≤ ω/(μg/kg) 2 1
金Gold≤ ω/(μg/kg) 2 1
铁Iron≤ ω/(μg/kg) 10 10
铅Plumbum≤ ω/(μg/kg) 2 1
锂Lithium≤ ω/(μg/kg) 2 1
镁Magnesium≤ ω/(μg/kg) 10 8
锰Manganese≤ ω/(μg/kg) 2 1
汞Mercury≤ ω/(μg/kg) 12 1
镍Nickel≤ ω/(μg/kg) 2 1
钾Kalium≤ ω/(μg/kg) 10 3
银Argentum≤ ω/(μg/kg) 2 1
钠Sodium≤ ω/(μg/kg) 10 5
锡Stannum≤ ω/(μg/kg) 2 1
锶Strontium≤ ω/(μg/kg) 2 1
钛Titanium≤ ω/(μg/kg) 2 1
钒Vanadium≤ ω/(μg/kg) 10 2
锌Zinc≤ ω/(μg/kg) 5 3
色度Chroma≤ APHA 60 60


产品用途 Application

        高纯三溴化硼11用于半导体工业包括集成电路、太阳能电池、半导体分离器件等作为P型掺杂源，通过热扩散对晶体硅进行P型掺杂。此外，三溴化硼还用做有机合成的催化剂、中间体和溴化剂以及制造高纯硼及其它有机硼化物的原料。
High pure boron11 tribromide is used as p-type doped sources in the semiconductor industry including integrated circuits, solar cells, semiconductor separation devices, etc., which doped crystal silicon with P-type dopant by thermal diffusion. In addition, boron tribromide is also used as a catalyst, intermediate and brominating agent for organic synthesis, as well as a raw material for the manufacture of high pure boron and other organoboron.

包装、贮存 Packaging and storage

        高纯三溴化硼11包装于石英瓶中，石英瓶外套厚质PVC塑料袋和不透光塑料膜，外包装箱为PE塑料材质，包装规格为1kg、5kg，具体包装规格可根据用户要求定制更改。产品贮存于阴凉、干燥仓房中，库温在20℃左右、相对湿度不超过75%。与碱类、醇类等分开存放，防潮、避光保存。
High pure boron11 tribromide is packed in a quartz bottle. The quartz bottle is covered with thick PVC plastic bag and opaque plastic film. The outer packing box is made of PE plastic material. The packaging specifications include 1 kg and 5 kg. Specific packaging specifications can be customized according to users’ requirements. The products are stored in a shady and dry storeroom with temperature around 20℃, relative humidity less than 75%. Keep away from alkali and alcohol, keep away from moisture and light.
